Copyright © 2011 Hunter Engineering Company Form 6409-T, 11/11
1111AH
Power Requirements
196-253V, 10 amp, 50/60 Hz, 1 ph (Power
cable includes: NEMA 20 amp plug, L6-20P)
Air Supply Requirements
100-175 psi (7-12 bar)
Roller Force
Variable up to 1,250 lbs (567 kg)
Capacity
Rim Width
1.5 in to 20.5 in (38 mm to 521 mm)
Rim Diameter
10 in to 30 in (254 mm to 762 mm)*
ALU
14 in to 44 in (356 mm to 1118 mm)*
Max. Tire Diameter
40 in (1016 mm)
Max. Tire Width
20 in (508 mm)
Max. Tire Weight
175 lbs (79 kg)
Radial and Lateral Runout Accuracy
0.002 in (0.051 mm)
Imbalance Resolution
± 0.01 oz (0.28 g)
Placement Accuracy
512 positions, ± 0.35°
Balancing Speed
290-300 rpm
Motor
Programmable drive system and DC motor
Shipping Weight
650 lbs to 850 lbs (295 kg to 385 kg)
Shipping Weight with Wheel Lift
750 lbs to 950 lbs (340 kg to 430 kg)
RF33GM RF32GM RF31GM RF30GM RF23GM RF22GM RF21GM RF20GM RF13GM RF12GM RF11GM RF10GM RF03GM RF02GM RF01GM RF00GM
Wheel Lift
System
AutoClamp
®
System
TDC Laser
System
Ink Jet Print
w/Storage
Width (W)
72 in
1829 mm
66 in
1676 mm
72 in
1829 mm
66 in
1676 mm
65 in
1651 mm
58 in
1473 mm
65 in
1651 mm
56.5 in
1435 mm
72 in
1829 mm
66 in
1676 mm
72 in
1829 mm
66 in
1676 mm
65 in
1651 mm
56.5 in
1435 mm
65 in
1651 mm
56.5 in
1435 mm
Height (H)
86 in
2184 mm
86 in
2184 mm
73 in
1854 mm
73 in
1854 mm
86 in
2184 mm
86 in
2184 mm
73 in
1854 mm
73 in
1854 mm
86 in
2184 mm
86 in
2184 mm
73 in
1854 mm
73 in
1854 mm
86 in
2184 mm
86 in
2184 mm
73 in
1854 mm
73 in
1854 mm
Depth (D)
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
62 in
1575 mm
RF03GM shown
Specifications
Models
Optional Accessories
3 3 3 3 3 3 3 3
3 3 3 3 3 3 3 3
3 3 3 3 3 3 3 3
33333333
Because of continuing technological
advancements, specifications, models and
options are subject to change without notice.
Hunter direct-fit collets
3 Only mounting adaptors approved
by GM
3 Accurately center-mount wheels
3 Avoid damage to plastic-clad wheels
Adjustable flange plate kit
3 Provides precise, accurate mounting
3 Prevents damage to rim
* Extreme wheel sizes may require manual data entry.
